Happy Place Size Guide
135 | 142 | 146 | 148 | 150 | 152 | 154 | 155w | 156 | 158 | 159w | 163w | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
MAX Rider Weight Range [kg] | 30-55 | 30-55 | 45-70 | 45-70 | 45-75 | 45-75 | 50-80 | 55-90 | 55-90 | 55-95 | 65-105 | 65-115 |
MAX Rider Weight Range [lbs] | 66-121 | 66-121 | 100-154 | 100-154 | 100-165 | 100-165 | 110-176 | 121-198 | 121-198 | 121-209 | 143-231 | 143-253 |
MAX Shoesize [EU] | 39 | 40 | 40 | 40 | 41 | 41 | 41 | 44 | 43 | 43 | 46 | 48 |
MAX Shoesize [US] | 6 | 6.5 | 6.5 | 7 | 8 | 8 | 8.5 | 10.5 | 9.5 | 10 | 13 | 15 |
MAX Sole Length [cm] | 23.5 | 24.1 | 24.1 | 24.4 | 25.4 | 25.4 | 25.7 | 27.3 | 26.7 | 27 | 29.4 | 31 |
MAX Sole Length [inch] | 9.2 | 9.5 | 9.5 | 9.6 | 9.9 | 9.9 | 10.1 | 10.7 | 10.4 | 10.5 | 11.5 | 12.1 |
Rider Height Range (cm) | 142 - 160 | 153 - 170 | 160 - 174 | 162 - 176 | 165 - 177 | 168 - 180 | 170 - 182 | 171 - 186 | 172 - 184 | 174 - 186 | 174 - 188 | 179 - 194 |
Rider Height Range (feet) | 4.7 - 5.2 | 5.0 - 5.6 | 5.2 - 5.7 | 5.3 - 5.8 | 5.4 - 5.8 | 5.5 - 5.9 | 5.6 - 6.0 | 5.6 - 6.1 | 5.6 - 6.0 | 5.7 - 6.1 | 5.7 - 6.2 | 5.9 - 6.4 |
CAMROCK
SPECS
SIZE [cm] | 135 | 142 | 146 | 148 | 150 | 152 | 154 | 155w | 156 | 158 | 159w | 163w |
NOSE LENGTH [mm] | 195 | 195 | 195 | 195 | 210 | 210 | 210 | 210 | 210 | 210 | 210 | 210 |
RUNNING LENGTH [mm] | 960 | 1030 | 1079 | 1090 | 1080 | 1100 | 1120 | 1130 | 1140 | 1160 | 1170 | 1210 |
TAIL LENGTH [mm] | 195 | 195 | 195 | 195 | 210 | 210 | 210 | 210 | 210 | 210 | 210 | 210 |
NOSE WIDTH [mm] | 274 | 281 | 285 | 286 | 289 | 290 | 292 | 300 | 294 | 296 | 302 | 309 |
WAIST WIDTH [mm] | 238 | 243 | 245 | 247 | 249 | 250 | 251 | 258 | 253 | 255 | 263 | 265 |
WAIST WIDTH [inch] | 9.4 | 9.6 | 9.6 | 9.7 | 9.8 | 9.8 | 9.9 | 10.2 | 10 | 10.1 | 10.4 | 10.4 |
TAIL WIDTH [mm] | 274 | 281 | 285 | 286 | 289 | 290 | 292 | 300 | 294 | 296 | 302 | 309 |
SIDECUT RADIUS [m] | 6.4 | 6.4 | 6.8 | 7 | 7.9 | 7.2 | 7.9 | 7.9 | 7.9 | 7.9 | 7.9 | 7.9 |
Min/Max STANCE [cm] | 46/58 | 46/58 | 46/58 | 46/58 | 46/58 | 46/58 | 50/62 | 50/62 | 50/62 | 50/62 | 54/66 | 54/66 |
Min/Max STANCE [inch] | 18.1/22.8 | 18.1/22.8 | 18.1/22.8 | 18.1/22.8 | 18.1/22.8 | 18.1/22.8 | 19.7/24.4 | 19.7/24.4 | 19.7/24.4 | 20.5/25.2 | 20.5/25.2 | 20.5/25.2 |
SETBACK [mm] | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
SETBACK [inch] | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
INSERTS [#] | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 | 6x2 |
